Reversing 256 Bits Without a Loop: A Lesson in EVM Optimization and defeating Dark Huffoor in Huff

I finally reached the end of the “Unveiling Huff” campaign on Node Guardians. After battling linear dispatchers and optimization puzzles, I faced the final boss: The Dark Huffoor.

The setup was classic RPG: The boss casts a darkSpell (a random bytes32 hash). To survive, I had to deflect it by casting a counterSpell.

The catch? The counterSpell had to be the exact Bitwise Reverse of the darkSpell. Oh, and I had a hard gas limit of 1,800 gas.

But What is Bit traversal sir ?

Bitwise reversal is the process of completely mirroring the binary representation of a number in opposite order.

Imagine the bits are written on a piece of transparent paper. “Reversing the bits” is like flipping that paper over horizontally:

The First bit of input becomes the Last bit of output.

The Last bit of input becomes the First bit of output.

Everything in the middle is swapped to its mirror position.

Take example from tests

dark spell : 0x61c831beab28d67d1bb40b5ae1a11e2757fa842f031a2d0bc94a7867bc5d26c2 counter spell : 0x4364ba3de61e5293d0b458c0f4215feae47885875ad02dd8be6b14d57d8c1386

Look at the start nibble of Input , 0x61 = 0110 0001 (cast to-base 0x61 bin) , reverse it 1000_0110 = 134 in decimals = 0x86 in hex , see last byte 86 of output

Now last bit of input 0xc2 = 11000010 , reverse it -> 01000011 = 0x43 ( start of output 43)

The Trap: Why Solidity Fails Here

If you were writing this in Solidity, your first instinct might be to use a loop.

function reverse(uint256 input) internal pure returns (uint256 reversed) {
    for (uint256 i = 0; i < 256; i++) {
        // Extract bit at i, move to (255 - i)...
        if ((input >> i) & 1 == 1) {
            reversed |= 1 << (255 - i);
        }
    }
}

Mathematically, this is O(n) complexity.

• Iterations: 256
• Cost per iteration: ~20-40 gas (optimistically)
• Total Cost: ~5,000 - 10,000 gas

With an 1,800 gas limit, a loop is dead on arrival. I needed a way to reverse 256 bits in O(1) (constant time).

The Magic: The Butterfly Algorithm ( Thanks my AI buddy + Brain )

The solution lies in a technique in Computer science we call the Divide and Conquer but for bit shifting let’s call it Butterfly method. Instead of moving bits one by one, we swap chunks of bits in parallel.

The strategy takes only 8 steps (because ):

To reverse bits in O(1) time (constant gas), we use the "Butterfly" method.

Instead of looping 256 times, we swap chunks of bits in parallel. (Generated using script/GenerateMasks.s.sol)

These constants act as filters to select specific chunks.

The Mask generation foundry script GenerateMasks.s.sol

// SPDX-License-Identifier: MIT
pragma solidity ^0.8.19;

import "forge-std/Script.sol";
import "forge-std/console.sol";

contract GenerateMasks is Script {
    function run() external view {
        console.log("// Paste this into your Huff file");
        console.log("// Generated by script/GenerateMasks.s.sol\n");

        printMask("M1", 1);
        printMask("M2", 2);
        printMask("M4", 4);
        printMask("M8", 8);
        printMask("M16", 16);
        printMask("M32", 32);
        printMask("M64", 64);
        printMask("M128", 128);
    }

    function printMask(string memory name, uint256 blockSize) internal view {
        uint256 mask = 0;

        // Loop through all 256 bits
        for (uint256 i = 0; i < 256; i++) {
            // Determine which "block" we are in.
            // Even blocks get 1s, Odd blocks get 0s.
            // Example M1 (size 1): Block 0->1, Block 1->0, Block 2->1 ...
            uint256 chunkIndex = i / blockSize;

            if (chunkIndex % 2 == 0) {
                // Set the bit at position i
                mask |= (1 << i);
            }
        }

        // Output in Huff format
        console.log(string.concat("#define constant ", name, "   = "));
        console.logBytes32(bytes32(mask));
    }
}

The Implementation in Huff

I defined a series of “Magic Masks” to select the chunks we wanted to swap.

• M1 = 0x55... (Binary 0101...) selects every other bit.
• M2 = 0x33... (Binary 0011...) selects pairs.
• M4 = 0x0F... (Binary 00001111...) selects nibbles.

Here is the REVERSE_BITS macro that costs only ~150 gas:

The main operation we see here is ((x & M1) << 1) | ((x >> 1) & M1) and later repeated for M2.M3…M128, let’s see more in depth what this shifting means in simple language

Deck of cards reversal

Imagine you have a deck of 8 cards (bits) numbered 0 to 7. You want to reverse them so they read 7 to 0.

Original: [7 6 5 4 3 2 1 0]

Step 1: Swap Adjacent Pairs (1-bit swap) We want to swap neighbors: (1,0), (3,2), (5,4), (7,6).

• We need a mask that selects every other bit to separate them.
• Pattern: 0 1 0 1 0 1 0 1
• Hex: 0x55
• Action: Shift the 0s left and the 1s right.
• Result: [6 7 4 5 2 3 0 1] (Neighbors are flipped!)

Step 2: Swap Adjacent 2-bit Chunks Now we treat them as blocks of 2. We want to swap (45, 67) and (01, 23).

• We need a mask that selects 2 bits, skips 2 bits.
• Pattern: 0 0 1 1 0 0 1 1
• Hex: 0x33
• Result: [4 5 6 7 0 1 2 3]

Step 3: Swap Adjacent 4-bit Nibbles Now we swap the left 4 with the right 4.

• Mask selects 4 bits, skips 4 bits.
• Pattern: 0 0 0 0 1 1 1 1
• Hex: 0x0F
• Result: [0 1 2 3 4 5 6 7] -> REVERSED!

So what this shifting actually does

Note: It’s oky if u don’t understand right away. please keep reading , you will get it.

So we see this code here

    dup1                // [x, x]
    [M1] and            // [x & M1, x]            <- Keep even bits
    0x01 shl            // [(x & M1) << 1, x]     <- Move evens to odd positions

    swap1               // [x, (x & M1) << 1]
    0x01 shr            // [x >> 1, (x & M1) << 1]
    [M1] and            // [(x >> 1) & M1, (x & M1) << 1] <- Keep original odds (now in even spots)

    or                  // [result_step_1]

This code has two halves/splits and hence two copies of x the number.Output of those two halves is Merged later in final step.

In the first half , we only keep even bits of number x and remove the odd bits from it and later transfer those even bits at odd positions in a fresh zero number( having same number of bits as x ) i.e 0x0000

the second half with new copy of x , remove even bits and keep odd bits but later transfer them to even positions in a new zero number i.e 0x0000

so we have

result1 : events bits moved to odd positions result2 : odd bits moved to even positions

when we finally OR them , we get the complete number Because It is The Merge.

i.e if the number was

111011 ( intuitively its reverse is 110111)

first half makes it only keep even bits that is 101, then in a new 0x000000 copy number , mves 101 to this number’s odd positions making it 0x100010

second half does opposite takes 111 ( odd digits and removes even bits) then in new copy say 0x000000 moves those 111(odd digits) at even positions i.e 0x010101

when we OR both of them

0x100010 0x010101

we get 110111 which is correct.

Note: read again if u are not fully confidant on your understanding or talk to an LLM about it . They are good in explanation mostly.

Now this logic was for reversing 1-bit pairs. since uint256 has 256 bits we have to do it multiple times i.e for

1 bit pairs 2 bit pairs 4 bit pairs 8 bit pairs 16 bit pairs 32 bit pairs 64 bit pairs 128 bit pairs

and then we stop because numbers are only 256 bits long. Once we do that , the number has already been reversed.

#define constant M1   = 0x5555555555555555555555555555555555555555555555555555555555555555
// ... (other constants M2, M4, M8, M16, M32, M64, M128)

#define macro REVERSE_BITS() = takes (1) returns (1) {
    // Input: [x]

        // ---------------------------------------------------------
    // Step 1: Swap adjacent bits (1-bit pairs)
    // ---------------------------------------------------------
    // We want to swap bits 0&1, 2&3, etc.
    // Left Logic:  Take bits at positions 0,2,4... (using M1), shift them LEFT to 1,3,5...
    // Right Logic: Take bits at positions 1,3,5... (shift RIGHT), isolate them (using M1)
    // Result:      Combine them with OR.

    dup1                // [x, x]
    [M1] and            // [x & M1, x]            <- Keep even bits
    0x01 shl            // [(x & M1) << 1, x]     <- Move evens to odd positions

    swap1               // [x, (x & M1) << 1]
    0x01 shr            // [x >> 1, (x & M1) << 1]
    [M1] and            // [(x >> 1) & M1, (x & M1) << 1] <- Keep original odds (now in even spots)

    or                  // [result_step_1]

    // ... (Steps 2 through 7) ...

    // Step 8: Swap 128-bit halves
    dup1 [M128] and 0x80 shl
    swap1 0x80 shr [M128] and or
}

The Full Solution: 3 Moves to Victory

My final MAIN macro had to execute a perfect sequence of moves to fit the gas budget.

1. The Parry (Selector Check)

The challenge required strict adherence to the interface. If the enemy cast anything other than takeDamage(), I had to revert immediately.

• Cost: ~20 Gas

2. The Steal (Staticcall)

I needed to read the darkSpell variable from the boss contract (msg.sender). I used a low-level STATICCALL, reusing memory slot 0x00 for both the outgoing selector (0xec24ac76) and the incoming result to save on memory expansion costs.

Inspiration of static call here : https://ethereum.stackexchange.com/questions/132961/call-another-contract-with-huff

• Cost: ~120 Gas

3. The Riposte (Bit Reversal)

I ran the darkSpell through the REVERSE_BITS macro.

• Cost: ~220 Gas

The Result

• Total Gas Used: ~894 Gas.
• Gas Limit: 1,800 Gas.
• Status: Crushed it.

Later i realized the official solution has used 1600+ gas and mine was ~900 gas. Man i’m really am levelling up i guess then.

However.This challenge was a potent reminder that algorithms matter. In high-level languages like Solidity, we often take for loops for granted. But when you are working at the metal, changing your algorithm from to isn’t just an optimization—it’s the difference between “Impossible” and “Easy”.

Thanks for reading.

Now, if you’ll excuse me, I have some bitmasks to generate.
